ETM Armaturen Butt Weld End Globe Valve Delivery To Europe

ETM Armaturen export the butt weld end globe valves to Europe.
ETM Armaturen all product's undercoat can withstand continuous exposure to up 400 degree.
ETM Armaturen will is a reliable and top quality supplier for you.

ETM Armaturen products will perfectly fit to your marker.

ETM Armaturen have enough experience for supply a top quality DIN & EN industrial valves to you.

Material Equivalence:

EN Material Name                    EN Number          Forgings          ASTM Material              Forgings

EN 10213 GP240GH                  1.0619             1.0460           ASTM A216 WCB           A105

EN 10213 G20Mo5                    1.6220             1.0437          ASTM A352 LCB             A352 LF2

EN 10213 G17CrMo5-5              1.7357             1.7335           ASTM A217 WC6           A182 F11

EN 10213 G17CrMo9-10             1.7379             1.7380           ASTM A217 WC9          A182 F22

EN 10213 GX5CrNi19-10            1.4308              1.4301          ASTM A351 CF8            A182 F304

EN 10213 GX5CrNi19-11-2         1.4408              1.4401          ASTM A351 CF8M          A182 F316

ETM FIG. S.150/151/152
DIN Gland Packing Globe Valves
Globe Valve / Feature:
Proven technology
Solid plug made of stainless material
Solid stem make of stainless material
Stem sealing in graphite Raised, turning stem
Back sealed stem Welded seat in stellite or Cr-steel
High-tensile Gland Packing Self adjusted gland
Plug disc,throttling disc,Balance disc design
DIN PN:PN16,PN25,PN40,PN63,PN100
DIN DN:DN15-DN400
Temperature Rating:-260°C up to +420°C
Body forms:Straight pattern body, Y-pattern body, Angle pattern body
Basic shell material:Low temperature carbon steel, Carbon steel, High temperature carbon steel, Stainless steel, High temperature stainless steel, High chromium stainless steel, Hastelloy, Inconel, Pure nickel, Titanium, Other special alloys
Connections:Flanged ends, Butt welding ends, Socket welding ends, Threaded ends, Other requirements
Operation:Handwheel, Lever, Chainwheel, Gear operator, Pneumatic piston actuator, Pneumatic diaphragm actuator, Electric actuator
Globe Valve / Applications: Industry, power stations , flue gas purification plant, processing technology, gas supply, vapour facilities, recycling facilities, vacuum facilities, hot water, heating technology, district heating, thermal oil applications, general plant manufacturing, etc.
Globe Valve / Mediums: Gases, hot water, thermal oil, process water, vacuum facilities, ammonia etc.
Stanrard material : GP240GH (1.0619/GS-C25),G-X6CrNi18.9(1.4308),G-X6CrNiMo18.10 (1.4408)
Design&manufacture standard conforms to EN 13709
Face to face standard conforms to EN 558-1
Flange standard conforms to EN 1092-1
Test conforms to EN 12266
